B22360(TG-106) Wall-Hung Stainless Steel Slop Hopper with Grid & Flush Valve
Image indicative of the range. Configurations may differ.
1 / 4 product images
Wall-mounted Grade 304 stainless steel slop hopper with a bucket grid and Walcro 106 flush valve. Available with or without an integral stainless steel P-trap.
Typical lead time
Current estimate: ± 10-15 working days. Final timing will be confirmed in your quotation.
Configure & quote
Choose a configuration
Your configuration
R12,815.00 (excl. VAT)
Ex works · Delivery charges excluded
Indicative pricing · final price confirmed in your quote
Prices shown are indicative and based on the latest available information. They may change with prevailing material costs, order quantities, specifications, and other requirements. Final pricing is confirmed in a formal quotation.
Integral stainless steel trap: Without Integral Trap
B22360(TG-106) is ready to quote.
Integral stainless steel trap
Selected model
B22360(TG-106)
Final pricing and delivery are confirmed in your quotation.
Talk to salesModel details
Overview
Wall-Mounted Grade 304 Stainless Steel Slop Hopper with Top-Entry Flush Pipe, Hinged Bucket Grid and Walcro 106 Flush Valve. Supplied Without an Integral Trap.
Loading model details…
Shortlist this product, add project notes and compare your options.
Product overview
Wall-mounted Grade 304 stainless steel slop hopper with a bucket grid and Walcro 106 flush valve. Available with or without an integral stainless steel P-trap.
The pressed and welded stainless steel construction has smoothly finished welds and a satin finish. The hinged bucket grid supports receptacles over the hopper and lifts for cleaning access.
Both configurations include a top-entry flush pipe, hinged bucket grid and Walcro 106 flush valve. B22360(TG-106) has no integral trap; B22360(TG-106-P) includes an integral stainless steel P-trap for a 110 mm soil-pipe connection.
Intended for waste disposal in hospital, clinic and institutional sluice rooms.
Compare the stainless steel slop hopper range.
Features & benefits
Grade 304 stainless steel
Pressed and welded stainless steel with a satin finish provides a smooth surface for routine cleaning.
Hinged bucket grid
The rear-hinged grid supports a bucket over the hopper and lifts to provide access for cleaning.
Integral stainless steel P-trap option
Choose the P-trap configuration where an integral stainless steel trap is required; the standard configuration is supplied without an integral trap.
Walcro 106 flush valve
Both configurations include the specified flush valve and top-entry flush pipe.
Installation & support
Technical information & documents
Product documents
Installation, specifications and warranty information.
Product specification sheet
Dimensions, materials and product data.
PDF
Product warranty
12-month warranty and claims information.
PDF
Need a drawing, CAD file or compliance certificate?
Request technical filesProduct data
Specifications & models
Specifications
- Integral stainless steel trap
- Configurable
- Without Integral Trap
- P-Trap
- Bucket Grid
- Fixed
- Yes
- Flushing Inlet Orientation
- Fixed
- Top Entry
- Material
- Fixed
- Stainless Steel Grade 304
| Specification | Value | Configuration |
|---|---|---|
| Integral stainless steel trap |
| Configurable |
| Bucket Grid |
| Fixed |
| Flushing Inlet Orientation |
| Fixed |
| Material |
| Fixed |
Available models & compare variants
Compare your preferred models
Select two to four models below. Your selection is kept when you search, filter or change pages.
| Price & actions | |||||||
|---|---|---|---|---|---|---|---|
| B22360(TG-106-P) | Grade 304 Stainless Steel Slop Hopper with Top-Entry Flush Pipe, Hinged Bucket Grid, Walcro 106 Flush Valve and Integral Stainless Steel P-Trap for 110 mm Soil Pipes. Slop Hopper with Flush Valve and Integral P-Trap | Yes | Top Entry | Stainless Steel Grade 304 | P-Trap | View specifications
| |
| B22360(TG-106) | Wall-Mounted Grade 304 Stainless Steel Slop Hopper with Top-Entry Flush Pipe, Hinged Bucket Grid and Walcro 106 Flush Valve. Supplied Without an Integral Trap. Slop Hopper (TG-106) | Yes | Top Entry | Stainless Steel Grade 304 | Without Integral Trap | View specifications
|
Specification support
Need a second set of eyes?
Product FAQ
