Hospitality & Foodservice

Overhead Pre-Rinse Spray with Mixer Taps. Optional and separately priced for compatible Basterfield sinks.

UR15TP 15 mm offset flush pipe for the recommended exposed flushing arrangement on the Basterfield B17744(T) top-entry bowl urinal. Use one 04VFP-UR15TP pipe with one 04VF_WAL-103LUR Walcro lever-operated flushing valve per bowl. The offset form provides the connecting pipework for this arrangement; check alignment against the installed bowl and valve positions. The pipe is a separately priced accessory and should be included whenever that valve is selected for the B17744(T) installation.

Walcro 103LUR exposed, lever-operated urinal flushing valve for a single bowl, with a 20 mm connection, chrome finish, flow control, strainer and no-hold feature. The stated operating pressure range is 30–600 kPa. Recommended as an optional flushing valve for the Basterfield B17744(T) top-entry bowl urinal, used with one 04VFP-UR15TP 15 mm offset flush pipe per valve. Specify both components together for this installation; the valve, pipe and stainless steel bowl are each priced separately.

Grade 304 stainless steel mixing paddle with a flat, square-edged face for stirring and mixing ingredients in food processing vessels.

Grade 304 stainless steel mixing paddle with rounded face corners, available with a solid or perforated face to suit the mixing task.

Grade 304 stainless steel mixing paddle combining square and rounded face edges, with solid and perforated options for different mixing tasks.

Grade 304 stainless steel mixing paddle with a square face and D-handle for stirring and handling ingredients in food processing vessels.

Straight general-purpose grab rail in Grade 304 stainless steel with a 32 mm diameter rail and mounting plates at both ends. Choose a 500 mm or 750 mm rail length for a wall-mounted handhold in washrooms, bathrooms and care facilities. Select the rail position and suitable wall fixings for the installation. The supplied image represents the range; the selected model determines the rail length.

Grade 304 stainless steel drop-in wash hand basin for installation into a countertop in commercial and institutional wash areas.

9 L Grade 304 stainless steel low-level cistern with right-hand flush handle as standard. Includes PVC flush pipe, flush valve, ball valve and rubber bung for a compatible back-entry stainless steel WC pan.

Basterfield floor-mounted WC pans in 1.2 mm Grade 304 stainless steel for schools, public and institutional washrooms. B17642(P) has a horizontal P-trap outlet; B17642(S) has a vertical S-trap outlet. Both feature a brushed satin finish, integral flushing rim, back-entry flush inlet and a 102 mm outside-diameter outlet for 110 mm PVC soil pipe. Floor flanges have 6 mm fixing holes. Seat holes are provided; toilet seats and flushing systems must be specified separately.

Grade 304 stainless steel curved-back trough urinal for flush-valve operation, with a concealed sparge pipe and selectable length and waste outlet position. B17720 is the alternative with built-in mechanical auto-flush.

Built-in Grade 304 stainless steel flat back urinal with a covered concealed sparge pipe, radiused drainage trough and left- or right-hand waste outlet.

Wall-hung Grade 304 stainless steel trough urinal for manual flush-valve installations. Choose one of nine lengths and a left- or right-hand 40 mm waste outlet. Optional 400 or 600 mm support brackets and the Walcro 550URV flush valve are priced separately.

Optional stainless steel support bracket for B17730 wall-hung trough urinals. Choose a 400 mm finished height for junior primary learners or a 600 mm finished height for senior primary, high school learners and adults.

Wall-mounted Grade 304 stainless steel bowl urinal for public and commercial washrooms, with integral brackets, a polished inner bowl, satin exterior, brass flush coupling and 40 mm waste opening. Choose B17744(B) back entry for concealed pipework or B17744(T) top entry for an exposed connection. Flush controls are optional: specify B17744(155UW) for back entry, or one Walcro 103LUR valve with one UR15TP offset pipe for top entry. The bowl and flushing accessories are priced separately.

Concealed back-entry 15 mm urinal flush system recommended as an optional accessory for the Basterfield B17744(B) wall-mounted bowl urinal. The push-button arrangement keeps the flush connection behind the bowl for a concealed pipework installation. Specify one system per back-entry bowl and coordinate the wall and plumbing layout before installation. Supplied and priced separately from the stainless steel bowl; select the matching inlet arrangement when planning a new washroom or replacement.

Grade 304 stainless steel privacy panel for installation between wall-mounted urinals. Fully welded with a satin finish, radiused front edge and heavy-duty concealed bracket for a clean, vandal-resistant installation. Suitable for new installations and retrofitting; substrate-specific wall fixings are not included.

Heavy-duty wall-mounted drip sink with grid, manufactured from 1.2 mm Grade 304 stainless steel. Measures 480 mm (L) x 460 mm (W) x 180 mm (H) for utensil and equipment drainage in janitorial, healthcare, catering and laboratory utility areas.

Grade 304 stainless steel wall-mounted waste bin with a satin polished finish, keyhole mounting slots and hemmed opening edges. Choose from 18, 21, 26, 30, 36, 45 or 64 L for everyday waste collection in washrooms, changing rooms and commercial or institutional facilities. The 64 L model measures 400 mm (L) x 300 mm (W) x 555 mm (H). Select capacity to suit the available space and emptying routine.

Large 2-compartment PPE dispenser in Grade 304 stainless steel, measuring 500 mm long x 170 mm wide x 220 mm high. A hinged lid provides refill access, while keyhole slots allow wall mounting at changing rooms, work-area entrances and PPE issue points. Use 2 separate compartments to organise suitable disposable PPE such as hair nets, beard covers, masks or shoe covers. Select the contents to suit the available space and the workplace PPE procedure.

Large 4-compartment PPE dispenser in Grade 304 stainless steel, measuring 1000 mm long x 170 mm wide x 220 mm high. A hinged lid provides refill access, while keyhole slots allow wall mounting at changing rooms, work-area entrances and PPE issue points. Use 4 separate compartments to organise suitable disposable PPE such as hair nets, beard covers, masks or shoe covers. Select the contents to suit the available space and the workplace PPE procedure.

Large single-compartment PPE dispenser in Grade 304 stainless steel, measuring 250 mm long x 170 mm wide x 220 mm high. A hinged lid provides refill access, while keyhole slots allow wall mounting at changing rooms, work-area entrances and PPE issue points. Use one compartment to organise suitable disposable PPE such as hair nets, beard covers, masks or shoe covers. Select the contents to suit the available space and the workplace PPE procedure.

Large 3-compartment PPE dispenser in Grade 304 stainless steel, measuring 750 mm long x 170 mm wide x 220 mm high. A hinged lid provides refill access, while keyhole slots allow wall mounting at changing rooms, work-area entrances and PPE issue points. Use 3 separate compartments to organise suitable disposable PPE such as hair nets, beard covers, masks or shoe covers. Select the contents to suit the available space and the workplace PPE procedure.
