B36150 Recessed Stainless Steel Hand Wash Basin and Drinking Fountain
Image indicative of the range. Configurations may differ.
1 / 1 product images
Recessed Grade 304 stainless steel handwash basin and drinking fountain, supplied fitted with a Walcro 101R chrome-plated DZR brass self-closing metered bib tap.
Typical lead time
Current estimate: ± 10-15 working days. Final timing will be confirmed in your quotation.
R4,106.00 (excl. VAT)
Indicative pricing · final price confirmed in your quote
Prices shown are indicative and based on the latest available information. They may change with prevailing material costs, order quantities, specifications, and other requirements. Final pricing is confirmed in a formal quotation.
Choose the quantity you need and add this item to your quote. We will confirm final pricing and delivery.
Shortlist this configuration, add project notes and compare your options.
Product overview
The Basterfield B36150 combines a handwash basin and drinking fountain in a compact recessed fixture for public and institutional sanitary areas. It is manufactured from heavy-duty Grade 304 stainless steel with a brushed finish.
The unit is supplied fitted with a Walcro 101R chrome-plated DZR brass self-closing metered bib tap. A drinking spout and concealed fittings are included in the arrangement.
B36150 measures 490 mm long x 370 mm wide x 125 mm high, has a 40 mm waste outlet and an approximate weight of 4 kg. Coordinate the wall recess, service access, water supply and waste connection with the installation layout.
The product is designed and manufactured in South Africa. Quote B36150 when ordering; B36150{PSS} is the applicable drawing/specification reference.
Features & benefits
Handwashing and drinking point
Combines a handwash basin and drinking fountain in one compact recessed fixture.
Walcro 101R tap included
Supplied fitted with a Walcro 101R chrome-plated DZR brass self-closing metered bib tap.
Grade 304 stainless steel
Heavy-duty Grade 304 stainless steel construction with a brushed finish.
Recessed installation
Designed for recessed mounting with concealed fittings for a clean installation.
Compact 490 x 370 x 125 mm size
The supplied specification gives overall dimensions of 490 mm long x 370 mm wide x 125 mm high.
40 mm waste outlet
Prepared for a 40 mm waste connection as stated on B36150{PSS}.
Installation & support
Technical information & documents
Product documents
Specification sheets, warranty information and technical media.
Product specification sheet
Dimensions, materials and product data for B36150.
PDFProduct warranty
12-month warranty and claims information for B36150.
PDFDrawings, manuals & certificates
Tell us if you need an installation manual, CAD file, drawing or compliance certificate.
Product data
Specifications & models
Specifications
Overall size envelope
- Height
- Fixed
- 125 mm
- Length
- Fixed
- 490 mm
- Width
- Fixed
- 370 mm
- Demand / Metered Tap
- Fixed
- Metered Tap
- Finish
- Fixed
- Satin Brushed Finish
- Material
- Fixed
- Stainless Steel Grade 304
- Mounting Type
- Fixed
- Recessed Mounting
- Waste Outlet Diameter
- Fixed
- 40 mm
- Weight
- Fixed
- 4 kg
| Specification | Value | Configuration |
|---|---|---|
| Demand / Metered Tap |
| Fixed |
| Finish |
| Fixed |
| Material |
| Fixed |
| Mounting Type |
| Fixed |
| Waste Outlet Diameter |
| Fixed |
| Weight |
| Fixed |
