ProductFloor Drains
B56100(112-2000-ST) 2000 mm Stainless Steel Floor Drain with 110 mm Outlet
Image indicative of the range. Configurations may differ.
1 / 2 product images
2000 mm heavy-duty stainless steel floor drain with a 110 mm spigot outlet for commercial and industrial drainage installations.
Typical lead time: ± 10-15 working days. Final timing will be confirmed in your quotation.
Price on request
Choose the quantity you need and add this item to your quote. We will confirm final pricing and delivery.
Share this model with a colleague or reopen its specifications later.
Shortlist this configuration, add project notes and compare your options.
Product overview
This Grade 304 stainless steel drainage channel is 2000 mm long and manufactured from 2 mm material. It has a 1:100 fall and a 110 mm spigot outlet.
A tiling key and casting lugs provide installation features. The drop-in grating has 4 mm wide slots.
Product data
Specifications & models
Specifications
Overall size envelope
- Length
- Fixed
- 2000 mm
- Drainage Channel Fall
- Fixed
- 1:100
- Grating Slot Width
- Fixed
- 4 mm
- Material
- Fixed
- Stainless Steel Grade 304
- Material Thickness
- Fixed
- 2 mm
- Waste Outlet Connection
- Fixed
- Spigot
- Waste Outlet Diameter
- Fixed
- 110 mm
| Specification | Value | Configuration |
|---|---|---|
| Drainage Channel Fall |
| Fixed |
| Grating Slot Width |
| Fixed |
| Material |
| Fixed |
| Material Thickness |
| Fixed |
| Waste Outlet Connection |
| Fixed |
| Waste Outlet Diameter |
| Fixed |
Specification support
Need a second set of eyes?
Installation & support
Technical information & documents
Product documents
Download installation, specification and warranty PDFs.
Product specification sheet
Dimensions, materials and product data.
PDF
Product warranty
12-month warranty and claims information.
PDF
Need a drawing, CAD file or compliance certificate?
Request technical files
