B17730 Wall Mounted Trough Urinal with Exposed Sparge Pipe

Durable and hygienic Grade 304 stainless steel urinal with exposed sparge pipe for effective surface rinsing. Wall-mounted with sloped drip ledge and sound-deadened back panel. Ideal for high-traffic public and commercial restrooms. Available in custom lengths with left/right waste outlet and optional flush system.

From: R4,418.00 Excl. VAT

Add to quote

Lead Time:

± 10-15 working days

This product is manufactured to order. If you have any questions about the lead time for a specific configuration or quantity, please don't hesitate to contact our team. We're happy to help!

Country of Origin: Manufactured in Johannesburg, South Africa

The B17730 Wall Mounted Trough Urinal is a robust, low-maintenance solution designed for demanding public and commercial environments. Manufactured from Grade 304 hygienic stainless steel, it provides exceptional resistance to corrosion, impact, and staining while delivering long-term performance with minimal upkeep.

The wall-mounted design eliminates the need for floor support and tiling, reducing installation time and cost. The exposed stainless steel sparge pipe delivers uniform water distribution, ensuring effective rinsing and maintaining high hygiene standards. A top water inlet and 40mm waste outlet (available in left- or right-hand configuration) support flexible plumbing integration.

The ergonomic design features a sloped drip ledge and deep trough projection to minimize splashback and promote user hygiene. A sound-deadened back panel prevents drumming and noise during use. Integrated stainless steel end panels allow for flush wall fitting or standalone installation.

Available in various lengths to suit different layouts, the B17730 can be paired with optional flush valves and cisterns upon request. The dull polished finish ensures an easy-to-clean, professional appearance, making it ideal for schools, public facilities, and commercial washrooms.

Specifications

FeatureSpecification
ModelB17730
MaterialGrade 304 Hygienic Stainless Steel
FinishDull Polished
MountingWall-mounted with pre-drilled fixing holes
Sparge PipeExposed, stainless steel; 28mm inlet (other sizes on request)
Water InletTop inlet
Waste Outlet40mm outlet hole; left-hand or right-hand configuration
Sound ReductionSound-deadened back panel
Design FeaturesSloped drip ledge and large trough projection to minimize splashback
End PanelsIntegrated stainless steel end panels for wall abutment or standalone installation
CustomizationAvailable in multiple lengths; optional flush valve and cistern available
Recommended UseSchools, universities, public restrooms, transport hubs, commercial facilities

Short Form Specification

Shall be B17730 wall-mounted trough type, manufactured from Grade 304 stainless steel with a dull polished finish. Unit shall include an exposed stainless steel sparge pipe with a 28mm top water inlet (other inlet sizes to be specified if required). The design shall include an ergonomic sloped drip ledge, sound-deadened back panel, and integrated stainless steel end panels. A 40mm waste outlet shall be provided in left-hand or right-hand configuration. Unit shall be available in multiple lengths to suit installation requirements and be compatible with optional flush valves and cistern systems.

Variations

Product CodeDescriptionLengthWaste Outlet Orientation
B17730(915L)B17730(915L) Wall Mounted Trough Urinal 915mm Length Left-Hand Outlet with Exposed Sparge Pipe915mmLeft Hand
B17730(915R)B17730(915R) Wall Mounted Trough Urinal 915mm Length Right-Hand Outlet with Exposed Sparge Pipe915mmRight Hand
B17730(1065L)B17730(1065L) Wall Mounted Trough Urinal 1065mm Length Left-Hand Outlet with Exposed Sparge Pipe1065mmLeft Hand
B17730(1065R)B17730(1065R) Wall Mounted Trough Urinal 1065mm Length Right-Hand Outlet with Exposed Sparge Pipe1065mmRight Hand
B17730(1220L)B17730(1220L) Wall Mounted Trough Urinal 1220mm Length Left-Hand Outlet with Exposed Sparge Pipe1220mmLeft Hand
B17730(1220R)B17730(1220R) Wall Mounted Trough Urinal 1220mm Length Right-Hand Outlet with Exposed Sparge Pipe1220mmRight Hand
B17730(1370L)B17730(1370L) Wall Mounted Trough Urinal 1370mm Length Left-Hand Outlet with Exposed Sparge Pipe1370mmLeft Hand
B17730(1370R)B17730(1370R) Wall Mounted Trough Urinal 1370mm Length Right-Hand Outlet with Exposed Sparge Pipe1370mmRight Hand
B17730(1525L)B17730(1525L) Wall Mounted Trough Urinal 1525mm Length Left-Hand Outlet with Exposed Sparge Pipe1525mmLeft Hand
B17730(1525R)B17730(1525R) Wall Mounted Trough Urinal 1525mm Length Right-Hand Outlet with Exposed Sparge Pipe1525mmRight Hand
B17730(1675L)B17730(1675L) Wall Mounted Trough Urinal 1675mm Length Left-Hand Outlet with Exposed Sparge Pipe1675mmLeft Hand
B17730(1675R)B17730(1675R) Wall Mounted Trough Urinal 1675mm Length Right-Hand Outlet with Exposed Sparge Pipe1675mmRight Hand
B17730(1830L)B17730(1830L) Wall Mounted Trough Urinal 1830mm Length Left-Hand Outlet with Exposed Sparge Pipe1830mmLeft Hand
B17730(1830R)B17730(1830R) Wall Mounted Trough Urinal 1830mm Length Right-Hand Outlet with Exposed Sparge Pipe1830mmRight Hand
B17730(2135L)B17730(2135L) Wall Mounted Trough Urinal 2135mm Length Left-Hand Outlet with Exposed Sparge Pipe2135mmLeft Hand
B17730(2135R)B17730(2135R) Wall Mounted Trough Urinal 2135mm Length Right-Hand Outlet with Exposed Sparge Pipe2135mmRight Hand
B17730(2440L)B17730(2440L) Wall Mounted Trough Urinal 2440mm Length Left-Hand Outlet with Exposed Sparge Pipe2440mmLeft Hand
B17730(2440R)B17730(2440R) Wall Mounted Trough Urinal 2440mm Length Right-Hand Outlet with Exposed Sparge Pipe2440mmRight Hand
