B17744 Bowl Urinals
1 / 7 product images
Wall-mounted Grade 304 stainless steel bowl urinal for public and commercial washrooms, with integral brackets, a polished inner bowl, satin exterior, brass flush coupling and 40 mm waste opening. Choose B17744(B) back entry for concealed pipework or B17744(T) top entry for an exposed connection. Flush controls are optional: specify B17744(155UW) for back entry, or one Walcro 103LUR valve with one UR15TP offset pipe for top entry. The bowl and flushing accessories are priced separately.
Typical lead time
Current estimate: ± 10-15 working days. Final timing will be confirmed in your quotation.
Configure & quote
Choose a configuration
R2,150.00 (excl. VAT)
Indicative pricing · final price confirmed in your quote
Prices shown are indicative and based on the latest available information. They may change with prevailing material costs, order quantities, specifications, and other requirements. Final pricing is confirmed in a formal quotation.
0 of 1 options selected
Select Flushing Inlet Orientation to complete your configuration.
Flushing Inlet Orientation
Complete the options above to review your configuration and request a quote.
Product overview
The Basterfield B17744 is a wall-mounted bowl urinal for individual use in public and commercial washrooms. Grade 304 stainless steel construction, a one-piece bowl, a smooth polished interior and a satin exterior support routine cleaning and daily use. Integral mounting brackets secure the bowl to the wall.
Choose the inlet arrangement to suit the plumbing layout. B17744(B) has back entry for concealed pipework. B17744(T) has top entry for an exposed flush connection. Both models include a brass flush coupling, a flush spreader and a 40 mm waste opening at the base. The waste opening describes the bowl aperture; confirm the required waste fitting and trap when specifying the installation.
For B17744(B), the recommended optional flush system is B17744(155UW), a concealed back-entry 15 mm push-button system. For B17744(T), specify one 04VF_WAL-103LUR Walcro lever-operated valve together with one 04VFP-UR15TP offset flush pipe per bowl. When selecting the top-entry valve, include the offset pipe. Flushing accessories are supplied and priced separately from the bowl.
Typical applications include public restrooms, school and university washrooms, restaurant ablutions and other commercial facilities. Confirm wall support, inlet alignment, waste connections and the selected valve's operating requirements before installation. The bowl urinal is designed and manufactured in South Africa.
Features & benefits
Grade 304 stainless steel
Stainless steel bowl for daily public and commercial washroom use.
Wall-mounted installation
Integral mounting brackets support wall installation.
Smooth bowl surfaces
One-piece bowl with polished interior and satin exterior.
Two inlet arrangements
Choose back entry for concealed pipework or top entry for an exposed connection.
Flush coupling and spreader
Brass coupling and flush spreader form part of the bowl arrangement.
40 mm waste opening
Base aperture for the specified waste fitting and trap arrangement.
Model-specific optional flushing
Back entry: B17744(155UW). Top entry: one 103LUR valve together with one UR15TP offset pipe.
Product data
Specifications & models
Specifications
- Flushing Inlet Orientation
- Configurable
- Back Entry
- Top Entry
- Material
- Fixed
- Stainless Steel Grade 304
| Specification | Value | Configuration |
|---|---|---|
| Flushing Inlet Orientation |
| Configurable |
| Material |
| Fixed |
Available models & compare variants
Compare 2 product variants
Filter the table and compare product codes, dimensions, attributes, and published pricing.
| Price | Spec sheet | Actions | ||||
|---|---|---|---|---|---|---|
| B17744(B) | Basterfield B17744(B) Wall-Mounted Grade 304 Stainless Steel Bowl Urinal to B17744{PSS}, Back Entry, Integral Brackets, Brass Flush Coupling, Flush Spreader and 40 mm Waste Opening. Recommended Optional Flush System: B17744(155UW), Concealed Back Entry, 15 mm, One per Bowl. Accessories Priced Separately. Grade 304 Bowl Urinal - Back Entry | Back Entry | Stainless Steel Grade 304 | R2,150.00 (excl. VAT) | ||
| B17744(T) | Basterfield B17744(T) Wall-Mounted Grade 304 Stainless Steel Bowl Urinal to B17744{PSS}, Top Entry, Integral Brackets, Brass Flush Coupling, Flush Spreader and 40 mm Waste Opening. Recommended Optional Flushing: One 04VF_WAL-103LUR Valve with One 04VFP-UR15TP Offset Pipe per Bowl. Include the Pipe When Selecting the Valve. Accessories Priced Separately. Grade 304 Bowl Urinal - Top Entry | Top Entry | Stainless Steel Grade 304 | R2,150.00 (excl. VAT) |
Specification support
Need a second set of eyes?
Installation & support
Technical information & documents
Product documents
Specification sheets, warranty information and technical media.
Product specification sheet
Dimensions, materials and product data for B17744.
PDFProduct warranty
12-month warranty and claims information for B17744.
PDFDrawings, manuals & certificates
Tell us if you need an installation manual, CAD file, drawing or compliance certificate.
