B17654(PT) Wall-Mounted Stainless Steel Toilet with Top Entry
1 / 2 product images
Wall-mounted stainless steel WC pan with P-trap and top-entry flush inlet for public, commercial and institutional washrooms. Toilet mounting holes are optional and omitted as standard. Excludes toilet seat and flush valve unless otherwise specified.
Typical lead time: ± 10-15 working days. Final timing will be confirmed in your quotation.
Configure & quote
Choose a configuration
Your configuration
R5,058.00 (excl. VAT)
Ex works · Delivery charges excluded
Indicative pricing · final price confirmed in your quote
Prices shown are indicative and based on the latest available information. They may change with prevailing material costs, order quantities, specifications, and other requirements. Final pricing is confirmed in a formal quotation.
Toilet mounting holes: Standard toilet mounting holes
B17654(PT-H) is ready to quote.
Toilet mounting holes
Selected model
B17654(PT-H)
Model details
Overview
Stainless Steel Toilet Wall Mounted with P-Trap, Top-Entry Flush Inlet and Standard Toilet Mounting Holes. Excludes toilet seat and flush valve unless otherwise specified.
The B17654 top-entry WC pan is a wall-mounted stainless steel toilet with a P-trap and a top-entry flush inlet. It is intended for public, commercial, educational and institutional ablution facilities.
Toilet mounting holes are omitted by default. Select the optional standard toilet mounting holes when required; the selected item code gains the -H suffix. For the P-trap, top-entry version, B17654(PT) has no toilet mounting holes and B17654(PT-H) has standard toilet mounting holes.
Excludes toilet seat and flush valve unless otherwise specified. A flushing system is selected and priced separately. Compatible top-entry models offer the B17110(L380-DPB) 9 L stainless steel cistern or, as an alternative, the Walcro 106T exposed lever-operated flushing valve with a 25 mm inlet. Select the flushing arrangement for the available water supply and installation layout.
Coordinate the wall support, waste outlet, flushing connection and selected seat with the site layout. Specify the mounting-hole option when ordering.
Specifications
B17654(PT-H). Stainless Steel Toilet Wall Mounted with P-Trap, Top-Entry Flush Inlet and Standard Toilet Mounting Holes. Excludes toilet seat and flush valve unless otherwise specified.
- Model: B17654(PT-H)
- Material: Stainless steel
- Mounting: Wall mounted
- Trap type: P-Trap
- Flushing inlet: Top Entry
- Toilet mounting holes: Standard toilet mounting holes
- Excluded: Toilet seat and flush valve unless otherwise specified
- Optional flushing: B17110(L380-DPB) cistern or Walcro 106T valve
Share this model with a colleague or reopen its specifications later.
Shortlist this configuration, add project notes and compare your options.
Product overview
The B17654(PT) top-entry WC pan is a wall-mounted stainless steel toilet with a P-trap and a top-entry flush inlet. It is intended for public, commercial, educational and institutional ablution facilities.
Toilet mounting holes are omitted by default. Select the optional standard toilet mounting holes when required; the selected item code gains the -H suffix. For the P-trap, top-entry version, B17654(PT) has no toilet mounting holes and B17654(PT-H) has standard toilet mounting holes.
Excludes toilet seat and flush valve unless otherwise specified. A flushing system is selected and priced separately. Compatible top-entry models offer the B17110(L380-DPB) 9 L stainless steel cistern or, as an alternative, the Walcro 106T exposed lever-operated flushing valve with a 25 mm inlet. Select the flushing arrangement for the available water supply and installation layout.
Coordinate the wall support, waste outlet, flushing connection and selected seat with the site layout. Specify the mounting-hole option when ordering.
Features & benefits
Wall-mounted WC pan
Stainless steel pan for wall-mounted installation.
Top-entry flushing option
P-trap top-entry models can use the optional B17110(L380-DPB) cistern or Walcro 106T valve.
No toilet mounting holes as standard
The default item has no toilet mounting holes. Select the optional holes version to add -H to the item code.
Seat and flush valve excluded
Excludes toilet seat and flush valve unless otherwise specified.
Product data
Specifications & models
Specifications
- Toilet mounting holes
- Configurable
- No holes
- Standard toilet mounting holes
- Flushing Inlet Orientation
- Fixed
- Top Entry
- Trap Type
- Fixed
- P-Trap
| Specification | Value | Configuration |
|---|---|---|
| Toilet mounting holes |
| Configurable |
| Flushing Inlet Orientation |
| Fixed |
| Trap Type |
| Fixed |
Available models & compare variants
Compare your preferred models
Select two to four models below. Your selection is kept when you search, filter or change pages.
| Price & actions | ||||||
|---|---|---|---|---|---|---|
| B17654(PT-H) | Stainless Steel Toilet Wall Mounted with P-Trap, Top-Entry Flush Inlet and Standard Toilet Mounting Holes. Excludes Toilet Seat and Flush Valve Unless Otherwise Specified. Wall-Mounted WC Pan, P-Trap, Top Entry -H | Standard toilet mounting holes | Top Entry | P-Trap | View specifications
| |
| B17654(PT) | Stainless Steel Toilet Wall Mounted with P-Trap, Top-Entry Flush Inlet and No Toilet Mounting Holes. Excludes Toilet Seat and Flush Valve Unless Otherwise Specified. Wall-Mounted WC Pan, P-Trap, Top Entry | No holes | Top Entry | P-Trap | View specifications
|
Specification support
Need a second set of eyes?
Installation & support
Technical information & documents
Product documents
Download installation, specification and warranty PDFs.
Product specification sheet
Dimensions, materials and product data.
PDF
Product warranty
12-month warranty and claims information.
PDF
